Trilux 7651 Emergency Lighting with Lens
Trilux 7651 Emergency Lighting with Lens ENDA Product
  • It remains true to itself – and yet consistently takes the next step forward. Typical for E-Line Next LED are not only pioneering achievements in terms of efficiency, service life, quality of light and convenience. The modular system with its unique range of variants ensures made-to-measure, perfect lighting conditions in every application. And when it comes to sustainability, no wishes remain unfulfilled. E-Line Next LED as a Monitoring-Ready version opens up the potential of intelligent and networked lighting. This makes it the ideal choice for all continuous line projects, across all applications.

Luminaire Type
Description Emergency Modules for Single or continuous line E-Line (7651) Trunking System
Application Areas Offices, Education, Warehouses, Manufacturing halls, Corridors, Assembly halls, Workshops
Mounting Methods Module suitable for E-Line (7651) Trunking System
Types 7651 LVN 9-840 EB1 TRI-PRO L75 01 / 7651 LVW 9-840 EB1 TRI-PRO L75 01 / 7651 LW 9-840 EB1 TRI-PRO L75 01
Optical System
Optics With PMMA optic lens system
Light Distribution Direct symmetric narrow/narrow-wide/wide beam light distribution
LED System - Light Source
Light Source LED technology
Luminous Flux 900lm
Connected Load 5W
Luminous Efficiency Energy efficiency up to 180lm/W
Light Colour 4000K
Colour Rendering Index Ra > 80
Housing
Housing Gear tray of sheet steel, LxWxH 737x78x62mm (with trunking)
Electrical Version
Electrical Version Emergency Lighting
Certificates - Standards
Protection Rate IP20
Safety Class Class I
Certificates CE, ENEC
