EI4430
48x48 mm, LCD Display, Selectable Analog Input Display
4 digits LCD display
Display scale can be adjusted between -1999 and 9999
Decimal point can be adjusted between 0 and 0.000 digits
Selectable four different standard input types (0-20mA, 4-20mA, 2-10V, 0-10V)
Adjustable input noise filtering
RS485 Modbus RTU communication protocol feature (order option)
CE marked according to European Norms
Manuals
Downloads
Environmental Conditions
Ambient/Storage Temperature
0...+50 ºC / -25...+70 ºC
Relative Humidity
80% Relative humidity for temperatures up to 31 °C, decreasing linearly to 50% at 40 °C
Protection Degree
According to EN 60529 Front panel:IP65, Rear panel:IP20
Height
Max. 2000m
Housing
Mounting Method
Panel mounting
Dimensions
W48xH48xD87 mm
Weight
Approx. 230g (after packaging)
Enclosure Material
Self extinguishing plastics
Electrical Characteristics
Supply
90-250V AC 50/60Hz or 10-30V DC/ 8-24V AC
Power Consumption
5VA
External Connections
Plug-in terminals
Scale
Adjustable between -1999...9999
Accuracy
2-10V DC: ±0.2% (of full scale) ±1 digit
0-10V DC: ±0.2% (of full scale) ±1 digit
0-20mA DC: ±0.2% (of full scale) ±1 digit
4-20mA DC: ±0.2% (of full scale) ±1 digit
0-10V DC: ±0.2% (of full scale) ±1 digit
0-20mA DC: ±0.2% (of full scale) ±1 digit
4-20mA DC: ±0.2% (of full scale) ±1 digit
